Ag/AgCl Electrodes

Ag/AgCl Pellets, Disc & Wire electrodes

Clear
Add to quote list
This product is already in quote request list
Browse the list
SKU: ALA-refp Category: Reference Electrodes Tags: Ag/AgCl electrodes, electrode holders, faraday cage, magnetic microscope stage tools, pipette holders, reference electrodes, silver silver chloride electrodes, slice grids, vacuum pump, vibration isolation tables
  • Overview
  • Specifications
  • Downloads
  • Ordering

Overview

A range of Ag/AgCl Reference electrodes from ALA Scientific suitable for use as reference electrodes are available. Made from very high purity materials using a careful proprietary process which results in a fine grain, homogeneous mixture of silver and silver chloride. A careful sintering process strengthens and stabilizes the entire electrode assembly.

These versatile electrodes have the consistency of soft metal and can be re-shaped by sanding, cutting, drilling and filing. Designed for use in electrochemistry, stimulation, precision bioelectric recording and electrophysiology.
Due to their stability and reproducible results, AG-AgCl electrodes are excellent for STANDARD and REFERENCE electrodes. Bare electrode pellets with wire have the same qualities as our wired electrodes, low offset voltage, stability, no re-chloriding, reusable and resurfacable, cold sterilization. The silver wire imbedded in the electrode is pure silver and allows for the specific connection that fits the users needs.

Last Updated on April 28, 2021

Specifications

DC Offset Voltage: 180μV

Drift: 25μV/hr

Noise: 1μ V peak to peak (0.1-1 kHz with 50 Hz eliminated)
(Measured in 0.9% saline, between pairs of Ag/AgCl electrodes of the same size)

Last Updated on April 28, 2021

Downloads

Reference Electrodes



Last Updated on April 28, 2021

Ordering

Part# Description
BMD-24
24MM DIA X 1MM DISK
BMD- 12x
12MM DIA X 1MM DISK (WITH HOLE)
BMD -12
12MM DIA X 1MM DISK
BMD-9x
9MM DIA X 1MM DISK (WITH HOLE)
BMD-9
9MM DIA X 1MM DISK
BMD-8
8MM DIA X 1MM DISK
BMD-6
6MM DIA X 1MM DISK
BMD-4
4MM DIA X 1MM DISK
BMP-2
2MM DIA X 4MM PELLET
BMP-1.5
1.5MM DIA X 3MM PELLET
BMP-1
1MM DIA X 2.5MM PELLET

Last Updated on April 28, 2021
