Overview
BNC type holders from ALA Scientific are made for use with all HEKA amplifiers, most npi electronic amplifiers, Dagan amplifiers, and any other amplifier with a BNC type connector.
Shown: PPH-2P-BNC (above) and PPH-1P-BNC (right)
All holders are made of low noise polycarbonate, come standard with an Ag wire, and accommodate glass OD of 1.5mm.
Options include an Ag/AgCl pellet instead of Ag wire, other glass sizes, and different configuration holders, like right angle and perfusion ports
Last Updated on October 17, 2024
Details
The HEKA pipette holder from HEKA, made of extremely low-noise polycarbonate, offers two major improvements that virtually eliminate pipette movement and air leakage by elongation of the holder’s cap and addition of a third o-ring. The longer cap allows for the insertion of a small polycarbonate cylinder, keeping the first o-ring firmly in place, even after removal of the cap for cleaning purposes. The second o-ring is nestled at the other end of the short cylinder featuring a precision mill cut that holds it in place.
This new design provides the highest pipette stability, eliminates air leaks, and extends the life time of o-rings. Most importantly, this new holder will increase the rate of successful recordings and increase productivity. All amplifiers (EPC 10, EPC 9, EPC 8, and EPC 7) come with the standard pipette holder for glass capillaries with an outer diameter of 1.5 mm. They are equipped with a BNC connector to fit to the headstages of the patch clamp amplifiers EPC 10, EPC 9, EPC 8, EPC 7 or potentiostat PG 300.
Last Updated on October 17, 2024
Downloads
Pipette Holders Product Literature
Last Updated on October 17, 2024
Ordering
| Part# |
Description |
| ALA PPH-0P-BNC |
BNC type straight holder with Ag wire and no side port |
| ALA PPH-1P-BNC |
BNC type straight holder with Ag wire and 1 side port |
| ALA PPH-1P-BNC45 |
BNC type 45 degree holder with Ag wire and 1 side port |
| ALA PPH-1P-BNC75 |
75 degree holder w/Ag wire and end port |
| ALA PPH-1P-BNC90 |
BNC type right angle holder with Ag wire and 1 side port |
| ALA PPH-2P-BNC |
BNC type straight holder with Ag wire and 2 ports |
| ALA PPH-2P-BNC90 |
BNC type right angle holder with Ag wire and 2 ports |
| ALA PPH-2P-BNCM |
Metal BNC type 45 degree perfusion holder with Ag wire and 2 ports |
Last Updated on October 17, 2024
