Carbon Fiber Electrodes

Voltammetry / Amperometry

  • Model: CFE-2
Add to quote list
Categories: , Tags: , , , , , , , , , , , ,

Overview

The Carbon Fiber Electrodes (CFE-2) from ALA Scientificare the ideal electrodes for voltammetric and amperometric studies. They are critical for identifying and determining the kinetics of released neurotransmitters. The CFE-2’s are made through parylene coating of paint which creates the highly sensitive environment for the detection of these small signals of interest. CFE-2’s  are sold in packs of 10.

Key features of CFE-2’s include:

  • 5μm OD carbon fibers for recording from small cells
  • Multiple re-uses due to easy re-cutting of tip
  • Slim design for use with water-immersion objectives

Last Updated on May 13, 2021

Details

Carbon Fiber Electrodes (CFE-2) from ALA Scientific  are safe and durable. Each tip is left extra long so that you can decide how short to cut it. Each tip can be cut back at least ten times. Each cut reveals a fresh 5μm OD carbon disk that is clean and ready for the next ReDox. The glass outer coating of the electrode body provides a strong mechanical support that is resistant to movement from temperature fluctuations. Other electrodes insulated with plastics can drift as temperatures change. In addition, glass does not absorb water, a factor that can induce noise, as much as polypropylene does. Each CFE-2 is also insulated with Sylgard, just like a patch electrode, to provide lower noise.

Coating of the CFE-2’s is done with Parylene. We can also fabricate carbon fiber electrodes with your own carbon fibers – please call or email to inquire.



Last Updated on May 13, 2021

Accessories

CFE-H-AXU: CFE Electrode Holder for Axon amplifiers

CFE-H-BNC: CFE Electrode Holder for amplifiers with BNC connectors

Last Updated on May 13, 2021

Downloads

CFE-2 Carbon Fiber Electrodes Literature

CFE-2 Carbon Fiber Electrodes Manual

Last Updated on May 13, 2021

Ordering

Part# Description
ALA CFE-2 Carbon Fiber Electrodes – pack of 10 – 5μm OD fibers
ALA CFE-H-AXU CFE-2 Electrode Holder for Axon amplifiers
ALA CFE-H-BNC CFE-2 Electrode Holder for amplifiers with BNC connectors

Last Updated on May 13, 2021

Research Papers

Jiang, Z.‐J., Delaney, T.L., Zanin, M.P., Haberberger, R.V., Pitson, S.M., Huang, J., Alford, S., Cologna, S.M., Keating, D.J. and Gong, L.‐W. (2019), Extracellular and intracellular sphingosine‐1‐phosphate distinctly regulates exocytosis in chromaffin cells. J. Neurochem., 149: 729-746. doi:10.1111/jnc.14703



Varga, K., Jiang, Z. and Gong, L.‐W. (2020), Phosphatidylserine is critical for vesicle fission during clathrin‐mediated endocytosis. J. Neurochem., 152: 48-60. doi:10.1111/jnc.14886

* Schulte. A., & Chow, R. Analytical Chemistry 1996, 68, 3054-3058



Synaptophysin Regulates Fusion Pores and Exocytosis Mode in Chromaffin Cells
Che-Wei Chang, Yu-Tien Hsiao, Meyer B. Jackson
Journal of Neuroscience 4 March 2021, JN-RM-2833-20; DOI: 10.1523/JNEUROSCI.2833-20.2021

Last Updated on May 13, 2021
