Dolan-Jenner Fiber Optic Illuminator

Straight Single Fiber Optic Light Guides

Dolan-Jenner standard light guides are made from .55N.A borosilica glass fibers with standard end tips that will easily adapt to Dolan-Jenner’s Fiber-Lite Illuminators. They are covered with a standard PVC covered mono-coil sheathing and have temperature ratings of -40 to 225 degrees Fahrenheit. They are available in varying lengths and diameters to suit your specific needs. If you are unable to find the fiber optic light guide to suit your needs please contact us as not all products are shown on website or check out our custom fiber optic capabilities.

Dual Branch Bifurcated Fiber Optic Light Guides

Dolan-Jenner bifurcated light guides are made from .55N.A borosilica glass fibers with standard end tips that will easily adapt to Dolan-Jenner’s Fiber-Lite Illuminators. They are covered with a standard PVC covered mono-coil sheathing and have temperature ratings of -40 to 225 degrees Fahrenheit. They are available in varying lengths and diameters to suit your specific needs. If you are unable to find the fiber optic light guide to suit your needs please contact us as not all products are shown on website or check out our custom fiber optic capabilities.

Gooseneck Light Guides

Dolan-Jenner’s Gooseneck light guides are self supporting, durable and adjustable. Gooseneck light guides provide light in the area where needed without additional stands or accessories. Gooseneck light guides come in both single and bifurcated configurations. Gooseneck light guides are available in multiple sizes and are also available in custom configurations.

Quartz Light Guides

Dolan-Jenner’s Quartz fiber optic light guides are available in both plastic cladded and quartz cladded fibers. Dolan-Jenners Quartz light guides provide higher temperature resistance up to 347 degrees farenheit. They are available in varying lengths and diameters with varying sheathing materials to better suit your needs. If you do not find a quartz fiber optic that will perform in your application feel free to contact us as not all products are shown on website or check out our custom fiber optics capabilities.

Special End Ferrules & Custom Light Guides

Our extensive standard product line of fiber optics and related components will fit a vast array of applications. If your application requires a custom designed fiber optic, we will be happy to assist you with your specific needs. If special configurations and materials are required in which our standard components can not be utilized, we have the resources and expertise available to manufacture to your specific requirements.

Fiber Optic Ring Lights

Dolan-Jenner’s ringlights provide intense shadow-free on –axis lighting and are especially useful when imaging highly reflective objects. All Dolan-Jenner ringlights provide 360 degrees of high intensity fiber optic illumination and feature industrial grade anodized aluminum or molded plastic housings. Glass fibers are sheathed in highly flexible PVC-covered steel monocoil or stainless steel armored jacket. To further reduce specular reflections from shiny surfaces, ringlights can be used in combination with a polarizer and analyzer. Custom sizes are available up to 12”

Line Lights

Dolan-Jenner provides a long line of fiber optic line lights. The line light design allows the structuring of light from a round light source into a line output configuration. Line-lights are extremely efficient in distributing extremely high levels of cold light and are easily used with Dolan-Jenner quartz halogen or strobe source. Fibers are randomized at input to provide a more uniform output of light. Line lights are available with material housings from metal to molds. Custom designs also available.

Back Lights

Back lighting is a machine vision lighting method which provides a high contrast silhouette of a part or part segment. Made with durable glass fiber optics, Dolan-Jenner backlights can be used with our Strobe-Optic strobe or any Fiber-Lite quartz halogen illuminators. The backlights are available in many different sizes and lengths and can also be customized to your individual use.

Fiber Optic Probe Kit

Dolan-Jenner fiber optic probes, also known as fiber optic light pipettes, are ideal for small bore illumination inspection and can be found in many medical labs for use in dissection and microsurgery. These small diameter stainless steel probes are available individually or as a kit including the fiber optic light guide and light source adapter.
