EPMS Housing

EPMS-07

Add to quote list
This product is already in quote request list
Browse the list
Category: Modular Housing and Power Supply Tags: amplifiers, bridge recording, electrophysiology rig, extracellular recording, in vitro recording, in vivo recording, intracellular recording, oocyte recording, patch clamp, patch clamp rig, single electrode voltage clamp, two elecrode voltage clamp, xenopus recording
  • Description
  • PWR-03D
  • Specifications
  • Downloads
  • Ordering

Description

EPMS-07:

  • The EPMS-07 is a modular system for measuring and/or processing of bioelectrical signals in electrophysiology and the application of substances in pharmacology.
  • The system is housed in a 19″ rackmount cabinet (3U) containing a power supply and has room for up to 7 plug-in units depending on the width of a module.
  • Modules can have a width of 1, 1.5, 2 or 3. The width of the modules in detail is given in the “Options” field for each module. The sum for one 19″ cabinet must not exceed seven.
  • The plug-in units are connected to mains by a bus at the rear panel.

EPMS-H-07:

  • In addition to the standard power supply of the EPMS-07, the EPMS-H-07 has a built-in high voltage power supply. This is necessary for all MVCS / MVCC modules, the HVA-100, HV-TR150 and HVC-03M modules. The output voltage depends on the modules in use.

EPMS-E-07:

  • Is used with an external power supply (PWR-03D, to be ordered separately).

EPMS-03:

  • The EPMS-03 is a modular system for measuring and/or processing of bioelectrical signals in electrophysiology and the application of substances in pharmacology.
  • The system is housed in a housing containing a power supply and has room for up to 3 plug-in units depending on the width of a module.
  • The plug-in units are connected to mains by a bus at the rear panel.

Last Updated on March 20, 2024

PWR-03D

Power supply for EMPS-E-07 or EXT-16DX systems

The external power supply PWR-03D is capable of driving up to three EPMS-E housings or one
EXT-16DX
 amplifier with one R/I-T1DX. Each housing is connected by a 6-pole cable from one
of three connectors on the front panel of the PWR-03D to the rear panel of the respective
EPMS-E or EXT-16DX / R/I-T1DX housing.

For more information, download the PWR-03D user manual.

Last Updated on March 20, 2024

Specifications

DIMENSIONS:
19” rackmount cabinet, for up to 7 plug-in units
Dimensions: 133.4 mm (3U) high (1U=1 3/4” = 44.45 mm), 302 mm deep

EPMS-07:
Power supply: 115/230 Volts AC, 60/50 Hz, fuse 2/1 A slow, 45-60 W (depending on the modules plugged in)

EPMS-E-07:
External power supply (for EPMS-E):      115/230 Volts AC, 60/50 Hz, fuse 1.6/0.8 A, slow
Dimensions of External power supply:     (W x D x H) 225 mm x 210 mm x 85 mm


EPMS-03:

Desktop cabinet, for up to 3 plug-in units
Power supply: 115/230 Volts AC, 60/50 Hz, fuse 0.8 A / 0.4 A slow
Maximum current supply: 500 mA
Dimensions: 3U high (1U=1 3/4” = 44.45 mm), 254 mm deep, 265 mm wide

Last Updated on March 20, 2024

Downloads

Manual:

Extracellular amplifiers

EPMS Housing Brochure

Last Updated on March 20, 2024

Ordering

Part No. Description
EPMS-07 With standard low-voltage power supply
suitable for all modules except MVCS, MVCC, HVC-03M and HVA-100 modules.
EPMS-H-07 With low- and high-voltage power supply
required for MVCS, MVCC, HVC-03M and HVA-100 modules.
EPMS-E-07 With external low-voltage low-noise power supply (PWR-03D, to be ordered separately).
EPMS-03 1/2 19″ cabinet with low-voltage power supply for up to 3 units.
PWR-03D Low-voltage low-noise power supply for up to 3 EPMS-E-07 housings.

Last Updated on March 20, 2024
