Description
The NE-9000 Programmable Peristaltic Pump is capable of continuous pumping at up to 900 mL/min through replaceable tubing that never comes into contact with the fluid. A computer or foot switch interface allows for programmable or manual production dispenses into multiple bottles, vials or other containers. Flow rates vary from a minimum of 0.041mL/min to a maximum of 904.4mL/min with 3/16 ID tubing. The chassis is only 7 3/4″ x 5 1/4″ and features an easy-to-use keypad interface.
Key features of the NE-9000 include:
- Dispense and withdrawal pumping
- Programmable “Learn and Repeat”™ control or manual foot switch control
- Slow down mode to improve accuracy of dispenses
- Anti-drip mode to stop oozing after dispenses
- Calibration mode to improve accuracy
- Programmable dispense volumes (store and select up to 40 dispenses)
- Non-volatile memory of all operating parameters and pumping program
- Programmable phases allowing complex pumping applications and interaction with external devices
- RS-232 bi-directional control for complete control from a PC; network up to 100 pumps and other devices
- Digital logic input: TTL I/O with software filtered control inputs to eliminate glitches and ringing on control inputs; configurable TTL operational trigger for foot switches and other devices
- Power failure mode restarts the pumping program after a power interruption
- Audible alarm
- Technical support
- Two year warranty
Last Updated on February 14, 2022
Ordering
| Part# |
Description |
| NE-9000B |
High flow rates & large dispense volumes. NE-9000 with 2 roller pumping head & 3/16″ ID tubing.
Flow rate ranges: 0.035 mL/min to 775.2 mL/min.
Includes PERI-HEAD-KIT-YB2 |
| NE-9000G |
Better precision with lower flow rates & small dispense volumes. NE-9000 with 4 roller pumping head & 1/16″ ID tubing
Flow rate ranges: 0.004 mL/min to 75.19 mL/min.
Includes PERI-HEAD-KIT-YG4 |
| NE-9004C |
Higher flow rates & larger dispense volumes. NE-9000 with 2 roller pumping head & 1/4″ ID tubing
Flow rate ranges: 0.047 mL/min to 1038 mL/min.
Includes PERI-HEAD-KIT-HGC2 |
| PERI-HEAD-KIT-YB2 |
Replacement head for model: NE-9000B. Also compatible with NE-9000G
2 roller pumping head, 3/16″ID tubing. Maximum pumping rate: 775.2 mL/min
Kit includes:
Blue, 2 roller head, 4 ft. Tubing
Model Q-TP-IND1-3/16
Industrial Grade 3/16″ID x 5/16″OD x 1/16″ Wall
Clamp ties: Nylon, quantity 4
Vial of lubrican |
| PERI-HEAD-KIT-YG4 |
Replacement head for model: NE-9000G. Also compatible with NE-9000B
4 roller pumping head, 1/16″ID tubing. Maximum pumping rate: 75.19 mL/min
Kit includes:
Green, 4 roller head, 4 ft. Tubing
Model Q-TP-PMED-1/16
Pharmed 1/16″ID x 3/16″OD x 1/16″ Wall
Clamp ties: Nylon, quantity 4
Reduction coupler, quantity 4
Vial of lubricant |
| PERI-HEAD-KIT-HGC2 |
Replacement head for model: NE-9004C
2 roller pumping head, 1/4″ID tubing. Maximum pumping rate: 1038 mL/min
Kit includes:
Clear, 2 roller head, 4 ft. Tubing
Model Q-TP-IND1-1/4
Industrial Grade 1/4″ID x 3/8″OD x 1/16″ Wall
Clamp ties: Nylon, quantity 4
Vial of lubricant |
