Overview
The Vacuum Waste Kit from ALA serves as an ideal suction source for light-duty suction jobs involving small cell chambers. The VWK can be incorporated easily into any set-up.
Key features of the VWK include:
- Maximum vacuum of -2.5psi (-17.2kPa)
- Quiet and compact aspiration pump
- Storage capacity of up to 2L
Last Updated on October 17, 2024
Details
Using the VWK in an experiment is very simple. The gauge will read the vacuum pressure in the flask. The needle valve is provided to reduce the amount of suction to your system or cell chamber.
The VWK comes with the following:
- 2L polyethylene flask
- Vacuum pump with gauge and needle valve
- Miscellaneous fittings and tubing’s
- Plastic stand
The plastic stand minimizes the footprint of the VWK.
Last Updated on October 17, 2024
Specifications
Dimensions
|
12″ x 10″ x 9″ / 30cm x 25.4cm / 23 cm |
Weight
|
3.2kg / 7 lb |
Tubing
|
1/16″ x 1/8″ / 1.6mm x 3.2mm Tygon |
Power Requirement
|
110/220VAC 3.5W |
Max Vacuum
|
-2.5psi / -17.2kPa |
Storage Container
|
2L polyethylene flask |
Last Updated on October 17, 2024
Ordering
Part# |
Description |
ALA VWK
|
Vacuum Waste Kit (can be used with LeveLock fluid chamber level controller) |
